Description
Digital Multimeter 5-in-1
• Five-in-one digital multi-tester has been designed to combine the functions of Sound Level Meter, Light Meter (Lux), Humidity Meter, Temperature Meter and Digital Multimeter.
• Conforms to IEC-1010 and CATIII 600V safety requirements for electrical equipment for measurement, control and laboratory use.
• Features integral upright stand, auto and manual range selection, data hold, relative measurement, auto power off function, LCD display and back light.
• Supplied with test probes and thermocouple.
Model No: | TM104 |
AC Voltage (Accuracy): | 4V, 400V (±0.8%), 600V (±1.5%) |
DC Voltage (Accuracy): | 0-400mV, 400V (±0.7%), 600V (±1.0%) |
AC Current (Accuracy): | 40mA, 400mA (±1.5%), 10A (±3.0%) |
DC Current (Accuracy): | 40mA, 400mA (±1.2%), 10A (±2.0%) |
Resistance (Accuracy): | 400?, 4M? (±1.2%), 40M? (±2.0%) |
Capacitance (Accuracy): | 4nF, 40µF (±3%), 200µF (±8%) |
Temperature (Accuracy): | -20°C-0°C (±5%), 0°C-20°C (±3%), 20°C-400°C (±2%) |
Frequency (Accuracy): | 9.999Hz (±2.0%), 99.99Hz, 9.999kHz (±1.5%), 99.99kHz, 199.99kHz (±2.0%) |
Duty Cycle: | 0.1%-99.9% (±3.0%) |
Continuity Audible: | Yes |
Diode Test: | Yes |
Transistor Test: | No |
Hi-Impact Rubber Case: | No |
Digits x Height: | 7 x 19mm |
Low Battery Indicator: | Yes |
Battery (Supplied): | 1 x 9V |
Information: | Data-Hold & Auto Power Off |
Size (L x W x D): | 178 x 85 x 40mm |
Weight: | 320g |
Conformity: | IEC 1010 |
Humidity: | 30-90% (±8%) |
Sound Level: | 35-100dB (±5dB at 94dB) |
Light: | 0-40,000Lux (±5%) (x10) |
